C64200 Flat-Bed Lathe Machine
Item Number: HP-LC-089
Machine Condition: NEW
Machine in stock: Machine Casting Body
Delivery time: 60 Days
Payment terms: T/T
Warranty: 1 Year
Afer Sales Service: Online support, Video technical support, Free spare parts
Product introduction
C64200 Flat-Bed Lathe Machine
SPECIFICATION | C64200MM |
Max.swing over bed | 2000mm |
Max.swing over cross slide | 1180mm |
Max. Load on Machine | 4000kg |
Chuck Size | 2000mm |
Center Distance | 1000mm |
Bed Width | 1100mm |
Spindle hole | 100mm |
Spindle nose | ISO-A2-20 |
Spindle speed(Number) | (4steps)1-160rpm |
Max.travel of top slide | 1024mm |
Max.travel of cross slide | 400mm |
Max.size of toolshank | 45*45m2 |
Longitudinal feeds range | 0.80 - 25 mm/min. |
Cross feeds range | 1.6 -50 mm/min. |
Main drive motor | 37KW |
Lubrication motor | 550W |
Coolant pump motor | 1.5W |
L*W*H(2000mm) | 365*115*190cm |
N.W/G.W(2000mm) | 8300/11000kgs |
C64160 Flat-Bed Lathe Machine / CWY6180XX2/3/4/5/6M Lathe Machine
